AEE 40W 高輸入雙輸出DC-DC轉換器

The AEE 40W series is a high efficiency, highly compact and high density DCDC converter designed to be used in applications where a very wide input voltage range is required.
型號 : aee 40w high i-p dual o-p series

The family covers an input voltage of 18Vdc to 75Vdc. The fully potted, metal cased construction also makes this family an ideal choice for harsh environments.
There are 2 output dual output voltage variants available
  • Total Max Power:
    40 W
  • Total Max Current:
    1.7 A
  • Input Voltage:
    18 V to 75 V
  • Output Voltage:
    -15 V to 15 V
  • Outputs:
    Dual
  • Size (L x W x H):
    2.000" x 1.000" x 0.400"
  • Warranty:
    2 years
  • Operating Temperature:
    -40°C to +85°C
