Product SKUs
|
|
AS -4124GO-NART+
|
|
Motherboard
|
|
Super H12DGO-6
|
|
Processor
|
|
CPU
|
-
Dual Socket SP3
-
AMD EPYC™ 7002/7003 Series Processors
|
|
Note
|
-
Supports up to 280W TDP CPUs (Air Cooled)
|
|
GPU
|
|
Max GPU Count
|
|
|
Supported GPU
|
-
NVIDIA SXM: HGX A100 8-GPU (80GB)
-
View GPU Options
|
|
GPU-GPU Interconnect
|
-
NVIDIA® NVLink™ with NVSwitch™
|
|
Certification
|
|
|
System Memory
|
|
Memory
|
-
Slot Count: 32 DIMM slots
-
Max Memory (2DPC): Up to 8TB 3200MT/s ECC DDR4 RDIMM/LRDIMM
-
View Memory Options
|
|
Memory Voltage
|
|
|
On-Board Devices
|
|
Network Connectivity
|
-
Ethernet
-
View AIOM Options
-
View AOC Options
|
|
IPMI
|
-
Support for Intelligent Platform Management Interface v.2.0
-
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
|
|
Input / Output
|
|
LAN
|
-
1 RJ45 1 GbE Dedicated BMC LAN port
|
|
USB
|
|
|
Video
|
|
|
System BIOS
|
|
BIOS Type
|
|
|
Management
|
|
Software
|
-
Supermicro Server Manager (SSM)
-
Supermicro Power Manager (SPM)
-
Supermicro Update Manager (SUM)
-
Supermicro SuperDoctor® 5 (SD5)
-
KVM with dedicated LAN
-
IPMI 2.0
-
Watch Dog
|
|
Security
|
|
Hardware
|
-
Trusted Platform Module (TPM) 2.0
-
Silicon Root of Trust (RoT) – NIST 800-193 Compliant
|
|
Features
|
-
Cryptographically Signed Firmware
-
Secure Boot
-
Secure Firmware Updates
-
Automatic Firmware Recovery
-
System Lockdown
|
|
PC Health Monitoring
|
|
CPU
|
-
4+1 Phase-switching voltage regulator
-
Monitors for CPU Cores, Chipset Voltages, Memory
|
|
FAN
|
-
Fans with tachometer monitoring
-
Pulse Width Modulated (PWM) fan connectors
-
Status monitor for speed control
|
|
Temperature
|
-
Monitoring for CPU and chassis environment
-
Thermal Control for fan connectors
|
|
|
|
Chassis
|
|
Form Factor
|
|
|
Model
|
|
|
Dimensions and Weight
|
|
Height
|
|
|
Width
|
|
|
Depth
|
|
|
Package
|
-
29.5" (H) x 27.4" (W) x 44.9" (D)
|
|
Weight
|
-
Gross Weight: 225 lbs (102.1 kg)
-
Net Weight: 166 lbs (75.3 kg)
|
|
Available Color
|
-
Black Front & Silver Body
|
|
Expansion Slots
|
|
PCI-Express (PCIe) Configuration
|
-
Default
-
1 PCIe 4.0 x16 LP slot
-
1 PCIe 4.0 x8 LP slot
-
View AOC Options
|
|
M.2
|
-
2 M.2 PCIe 4.0 x4 slots (M-key 22110)
|
|
Drive Bays / Storage
|
|
Drive Bays Configuration
|
-
Default: Total 6 bays
-
6 front hot-swap 2.5" NVMe drive bays
-
Option A: Total 10 bays
-
6 front hot-swap 2.5" NVMe drive bays
-
4 rear hot-swap 2.5" NVMe drive bays
-
View NVMe Options
-
View Drive Options
|
|
M.2
|
-
2 M.2 NVMe slots (M-key)
-
View M.2 Options
|
|
System Cooling
|
|
Fans
|
-
Up to 4 x Hot-swap 11.5K RPM heavy duty Fan(s)
|
|
Power Supply
|
|
|
4x 3000W Redundant (2 + 2) Titanium Level (96%) power supplies
|
|
Dimension (WxHxL)
|
106.5 x 82.4 x 203.5 mm
|
|
Input
|
2880W: 200-207Vac
2880W: 200-207Vac / 50-60Hz
3000W: 207.1-240Vac
3000W: 240Vdc
3000W: 207.1-240Vac / 50-60Hz
3000W: 240Vdc / 50-60Hz
|
|
+12V
|
Max: 91.66A / Min: 0A (Vdc-240Vdc)
Max: 91.66A / Min: 0A (200Vac-240Vac)
|
|
12V SB
|
Max: 4A / Min: 0A
|
|
Output Type
|
Backplanes (gold finger)
|
|
Operating Environment
|
|
ROHS
|
|
|
Environmental Spec.
|
-
Operating Temperature: 10°C to 35°C (50°F to 95°F)
-
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
-
Operating Relative Humidity: 8% to 90% (Non-Condensing)
-
Non-operating Relative Humidity: 5% to 95% (Non-Condensing)
|
|
For detailed specifications, options, and compatibility, please refer to the latest official Supermicro documentation and the actual quotes/specifications from Autech.
-
Supports NVIDIA® HGX™ A100 8-GPU
Highest GPU communication using NVIDIA® NVLINK™ v3.0 + NVIDIA® NVSwitch™
NICs for GPUDirect RDMA (1:1 GPU Ratio)
Supports HGX A100 8-GPU 40GB (HBM2) or 80GB (HBM2e)
-
Dual AMD EPYC™ 7003/7002 Series Processors
(The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)
-
8TB Registered ECC DDR4 3200MHz SDRAM in 32 DIMMs
-
8 PCIe 4.0 x16 via PCIe switch
1 PCIe 4.0 x 16 LP and 1 PCIe 4.0 x8 LP via CPUs
AIOM Support
-
6 Hot-swap 2.5" NVMe drive bays
(4 via PCIe switch, 2 via CPU)
Up to 10 NVMe 2.5" drives available with an optional 4 drive bays at rear of system
