SuperWorkstation SYS-532AW-C

SYS-532AW-C

SYS-532AW-C 為 Supermicro SuperWorkstation 伺服器等級工作站，適合專業運算、工程模擬、內容創作與企業級工作站應用。

型號 : SYS-532AW-C

數量 :

SYS-532AW-C 是 Supermicro SuperWorkstation 系列伺服器等級工作站，設計用於高效能專業運算、工程設計、視覺化、AI 開發與企業級創作工作流程。

本頁資料依據 Supermicro 官方產品系列與亞郁既有產品頁格式恢復建立，詳細規格與可配置選項請以原廠最新資料與實際報價規格為準。

以下規格依據 Supermicro 官方 SYS-532AW-C 產品頁整理，實際出貨配置仍以 AUTECH 報價與原廠最新資料為準。

Product SKUs
SuperWorkstation SYS-532AW-C

Motherboard
Super X14SAE

Processor
CPU	Single LGA-1851 Intel® Core™ Ultra 9/7/5 (Series 2) processors
Core Count	Up to 24C/24T; Up to 36MB Cache
Note	Supports up to 125W TDP CPUs (Air Cooled)

GPU
Max GPU Count	Up to 1 triple-width or 1 double-width GPU
Supported GPU	NVIDIA PCIe: RTX 5000 Ada, RTX 6000 Ada Generation NVIDIA: GeForce RTX 5070, GeForce RTX 5080, GeForce RTX 5090

System Memory
Memory	Slot Count: 4 DIMM slots Max Memory (2DPC): Up to 192GB 5600MT/s ECC/non-ECC DDR5 UDIMM
Memory Voltage	1.1V

On-Board Devices
SATA	SATA (6Gbps) via Intel® W880; RAID 0/1/5/10 support
Chipset	Intel® W880
Network Connectivity	1 RJ45 1GbE with Intel® I219-LM 1 RJ45 2.5GbE with Intel® I226-LM

Input / Output
USB	2 USB 3.2 Gen1 Type-A ports (front) 3 USB 3.2 Gen2 Type-A ports (rear) 1 USB 3.2 Gen2 Type-C port (rear) 1 USB 3.2 Gen2 Type-C port (front) 1 Thunderbolt™ 4 Type-C port (rear)
Video	1 HDMI 2.1 port (rear) 1 DisplayPort 2.1 port (rear)
Audio	7.1 HD Audio
TPM	1 TPM Onboard TPM & TPM Header

System BIOS / Management / Security
BIOS Type	AMI 256MB SPI Flash
Management Software	Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO)
Power Configurations	ACPI 6.0 Power Management
Security Features	Cryptographically Signed Firmware Secure Boot
Security Hardware	Trusted Platform Module (TPM) 2.0

PC Health Monitoring
Voltage	+1.0V PCH, +1.8V PCH, +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 3.3V standby, 5 (4-pin), CPU, CPU temperature, CPU thermal trip support, PCH temperature, System temperature, VBAT, VRM temperature

Dimensions and Weight
Height	17.72" (450 mm)
Width	8.07" (205 mm)
Depth	18.5" (470 mm)
Package	24.29" (H) x 12.8" (W) x 23.23" (D)
Weight	Gross Weight: 19.2 lbs (8.7 kg) Net Weight: 14.1 lbs (6.4 kg)
Available Color	Black

Front Panel
Buttons	Power On/Off
LED	HDD activity Power status LED
Port	Audio Jack-Combo microphone input / audio output port USB Type-A Ports: USB 3.2 Gen 1x1 ports (5G) USB Type-C: USB 3.2 Gen 2x2 port (20G)

Expansion Slots
PCI-Express (PCIe) Configuration	Default: 2 PCIe 5.0 x8 (in x16) FHFL slots; 1 PCIe 4.0 x4 (in x4) FHHL slot Option A: 1 PCIe 5.0 x16 (in x16) FHFL slot; 1 PCIe 4.0 x4 (in x4) FHHL slot
M.2	1 M.2 PCIe 5.0 x4 NVMe slot (M-key 2280 default) 1 M.2 PCIe 4.0 x4 NVMe slot (M-key 22110 default / 2280)

Drive Bays / Storage
Drive Bays Configuration	Default: Total 6 bays 2 internal fixed 3.5"/2.5" SATA drive bays 4 internal fixed 2.5" NVMe/SATA drive bays NVMe support may require additional storage controller and/or cables
M.2	1 M.2 PCIe 4.0 x4 NVMe slot (M-key 22110 default / 2280) 1 M.2 PCIe 5.0 x4 NVMe slot (M-key 2280 default)

System Cooling
Fans	Up to 4x 120mm fan(s)

Operating Environment
Environmental Spec.	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)
