• MBD-X10DRH-i (16 DIMMs 12

MBD-X10DRH-i (16 DIMMs 12" x 13")

Dual socket R3 (LGA 2011) supports Intel® Xeon® processor E5-2600 v4†/v3 family; UPI up to 9.6GT/s,Intel® C612 chipset,Up to 2TB† ECC 3DS LRDIMM , up to DDR4- 2400†MHz; 16 DIMM slots,1 PCI-E 3.0 x16, 6 PCI-E 3.0 x8 slots,Intel® i350 Dual port GbE LAN
型號 : X10DRH-i

  1. Dual socket R3 (LGA 2011) supports Intel® Xeon® processor E5-2600 v4†/ v3 family; UPI up to 9.6GT/s
  2. Intel® C612 chipset
  3. Up to 2TB† ECC 3DS LRDIMM , up to
    DDR4- 2400†MHz; 16 DIMM slots
  4. 1 PCI-E 3.0 x16, 6 PCI-E 3.0 x8 slots
  5. Intel® i350 Dual port GbE LAN
  6. 10 SATA3 (6Gbps) ports w/ Intel®
    C612 controller; RAID 0, 1, 5, 10
  7. Integrated IPMI 2.0 and KVM with Dedicated LAN
  8. 5 USB 3.0 and 4 USB 2.0 ports

Parts List

Parts List (Bulk Package)
Name Part Number Qty Description
Motherboard MBD-X10DRH-i 1 X10DRH-i Motherboard
Quick Reference Guide MNL-1628-QRG 1 Quick Reference Guide
I/O Shield MCP-260-00042-0N 1 STD I/O shield for X9 socket R server MB with Gasket
I/O Cables CBL-0044L 2 SATA CABLE 61CM FLAT S-S PBF

Optional Parts List
Name Part Number Qty Description
Heat Sink (optional, not included) -- CPU Heat Sink reference
TPM security module (optional, not included) AOM-TPM-9655V
AOM-TPM-9655H
-- TPM 1.2 module with Infineon 9655, RoHS/REACH, PBF; Vertical or Horiztonal depends on the server
TPM security module (optional, not included) AOM-TPM-9655V-S
AOM-TPM-9655H-S
-- TPM 1.2 module with Infineon 9655, RoHS/REACH, PBF; Vertical or Horiztonal depends on the server, provision for TXT
TPM security module (optional, not included) AOM-TPM-9665V
AOM-TPM-9665H
-- TPM 2.0 module with Infineon 9665, RoHS/REACH, PBF; Vertical or Horizontal depends on the server
TPM security module (optional, not included) AOM-TPM-9665V-S
AOM-TPM-9665H-S
-- TPM 2.0 module with Infineon 9665, RoHS/REACH, PBF; Vertical or Horizontal depends on the server, provisioned for TXT
SuperDOM -- Supermicro SATA DOM Solutions [Details]
I/O Cables CBL-0097L-03 2 30AWG 50CM IPASS TO 4 SATA W/50CM SB, S
