| Product SKUs | | AS -4125GS-TNRT2 | | Motherboard | | Super H13DSG-O-CPU | | Processor | | CPU | - Dual processor(s)
- AMD EPYC™ 9004/9005 Series Processors
(* AMD EPYC™ 9005 Series drop-in support requires board revision 2.x)
| | Core Count | - Up to 160C/320T; Up to 512MB Cache per CPU
| | Note | - Supports up to 400W TDP CPUs
| | GPU | | Max GPU Count | - Up to 10 double-width GPUs
| | Supported GPU | - NVIDIA PCIe: L4, L40S, NVIDIA RTX PRO™ 4500 Blackwell Server Edition, NVIDIA RTX PRO™ 5000 Blackwell, NVIDIA RTX PRO™ 6000 Blackwell Max-Q Workstation Edition, RTX 4000 Ada Generation, RTX 4000 SFF Ada Generation, RTX 4500 Ada, RTX 5000 Ada, RTX 6000 Ada Generation
- AMD PCIe: Instinct™ MI210
- View GPU Options
| | CPU-GPU Interconnect | - PCIe 5.0 x16 Switch Dual-Root
| | GPU-GPU Interconnect | - NVIDIA® NVLink™ Bridge (optional), AMD Infinity Fabric™ Link (optional)
| | System Memory | | Memory | - Slot Count: 24 DIMM slots
- Max Memory (1DPC): Up to 6TB 4800MT/s ECC DDR5 RDIMM (AMD EPYC™ 9004 Series Processor)
- Max Memory (1DPC): Up to 6TB 6000MT/s ECC DDR5 RDIMM (AMD EPYC™ 9005 Series Processor)
- View Memory Options
| | Memory Voltage | | | On-Board Devices | | SATA | | | Chipset | | | Network Connectivity | - 2 RJ45 10GbE
- View AIOM Options
- View AOC Options
| | Input / Output | | LAN | - 1 RJ45 1 GbE Dedicated BMC LAN port
- 2 RJ45 10 GBASE-T LAN ports
| | USB | | | Video | | | Serial | | | System BIOS | | BIOS Type | - AMI 32MB SPI Flash EEPROM
| | Management | | Software | - SuperCloud Composer®
- Supermicro Server Manager (SSM)
- Supermicro Update Manager (SUM)
- Supermicro SuperDoctor® 5 (SD5)
- Super Diagnostics Offline (SDO)
- Supermicro Thin-Agent Service (TAS)
- SuperServer Automation Assistant (SAA) New!
| | Power configurations | - Power-on mode for AC power recovery
- ACPI Power Management
| | Security | | Hardware | - Trusted Platform Module (TPM) 2.0
- Silicon Root of Trust (RoT) – NIST 800-193 Compliant
| | Features | - Cryptographically Signed Firmware
- Secure Boot
- Secure Firmware Updates
- Automatic Firmware Recovery
- Supply Chain Security: Remote Attestation
- Runtime BMC Protections
- System Lockdown
| | PC Health Monitoring | | CPU | - 7 +1 Phase-switching voltage regulator
- Monitors for CPU Cores, Chipset Voltages, Memory
| | FAN | - Fans with tachometer monitoring
- Pulse Width Modulated (PWM) fan connectors
- Status monitor for speed control
| | Temperature | - Monitoring for CPU and chassis environment
- Thermal Control for fan connectors
|
| | | Chassis | | Form Factor | | | Model | | | Dimensions and Weight | | Height | | | Width | | | Depth | | | Package | - 26.57" (H) x 27" (W) x 41" (D)
| | Weight | - Gross Weight: 100 lbs (45.3 kg)
- Net Weight: 65.5 lbs (29.7 kg)
| | Available Color | - Black Front & Silver Body
| | Front Panel | | Buttons | - Power On/Off button
- System Reset button
| | LED | - Hard drive activity LED
- Network activity LEDs
- Power status LED
- System Overheat & Power Fail LED
| | Expansion Slots | | PCI-Express (PCIe) Configuration | - Default
- 11 PCIe 5.0 x16 FHFL slots
- Option A
- 13 PCIe 5.0 x16 FHFL slots
- View AOC Options
| | Drive Bays / Storage | | Drive Bays Configuration | - Default: Total 10 bays
- 8 front hot-swap 2.5" NVMe drive bays
- 2 front hot-swap 2.5" SATA drive bays
- View NVMe Options
- View Drive Options
| | M.2 | - 1 M.2 PCIe 3.0 x4 NVMe slot (M-key)
- View M.2 Options
| | System Cooling | | Fans | - Up to 8 heavy duty fans with optimal fan speed control
| | Power Supply | | | 4x 2000W Redundant (3 + 1) Titanium Level (96%) power supplies | | Dimension (WxHxL) | 73.5 x 40 x 203 mm | | Input | 1000W: 100-127Vac
1000W: 100-127Vac / 50-60Hz
1800W: 200-220Vac
1800W: 200-220Vac / 50-60Hz
1980W: 220-230Vac
1980W: 220-230Vac / 50-60Hz
2000W: 230-240Vdc
2000W: 220-240Vac
2000W: 230-240Vac
2000W: 230-240Vac / 50-60Hz
2000W: 220-240Vac / 50-60Hz (for UL only)
2000W: 230-240Vdc / 50-60Hz (for China only) | | +12V | Max: 83A / Min: 0A (100Vac-127Vac)
Max: 150A / Min: 0A (200Vac-220Vac)
Max: 165A / Min: 0A (220Vac-230Vac)
Max: 166A / Min: 0A (230Vac-240Vac) | | 12V SB | Max: 3.5A / Min: 0A
Max: 3.5A | | Output Type | Backplanes (gold finger) | | Operating Environment | | Environmental Spec. | - Operating Temperature: 10°C to 35°C (50°F to 95°F)
- Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
- Operating Relative Humidity: 8% to 90% (non-condensing)
- Non-operating Relative Humidity: 5% to 95% (non-condensing)
|
|
For detailed specifications, options, and compatibility, please refer to the latest official Supermicro documentation and the actual quotes/specifications from Autech.
-
Flexible GPU support: active & passive GPUs
Dual Root Configuration with PCIe Switch for up to 10 double width, full length GPUs
8 Hot-Swap Heavy Duty Fans with Optimal Fan Speed Control
-
Dual-Socket, AMD EPYC™ 9004/9005 Series Processors up to 400W TDP
-
Supports up to 24 DIMM Slots, 6000 MT/s 6TB DDR5 memory
(Please check System Memory Section for detail)
-
AIOM / OCP 3.0 Support
-
Total of 8 Hot-swap 2.5" NVMe drive bays, 1 onboard Gen3 M.2 Slot
-
Total of 4x 2000W Redundant (2+2 or 3+1) Titanium Level power supplies
(2+2 under 4000 Watt, 3+1 under 6000 Watt)
(Power supply full redundancy based on configuration and application load)
-
AI / Deep Learning
-
Big Data Analytics and AI
-
High Performance Computing
-
Engineering/scientific research
