SYS-530AD-I 是 Supermicro SuperWorkstation 單處理器伺服器等級工作站。適用於遊戲與內容創作的單路中塔式工作站。
本機型面向需要可靠運算、儲存、擴充與專業圖形配置的工作站部署。主要配置參考包含 11th Gen Intel® Core™ Processors、Mid-Tower、6 default 與 1x 750W。
原廠參考連結:Supermicro 原廠產品頁面
|
Product SKUs
|
|
SYS-530AD-I
|
|
Motherboard
|
|
Super C9Z590-CG
|
|
Processor
|
|
CPU
|
-
Single Socket H5 (LGA-1200)
-
11th Gen Intel® Core™ Processors
|
|
Core Count
|
-
Up to 8C/16T; Up to 16MB Cache
|
|
Note
|
-
Supports up to 125W TDP CPUs (Air Cooled)
|
|
GPU
|
|
Max GPU Count
|
|
|
System Memory
|
|
Memory
|
-
Slot Count: 4 DIMM slots
-
Max Memory (2DPC): Up to 4TB 3200MT/s non-ECC DDR4 UDIMM
-
View Memory Options
|
|
Memory Voltage
|
|
|
On-Board Devices
|
|
SATA
|
|
|
Network Connectivity
|
-
1 RJ45 1GbE with Intel® PHY I219-V
-
1 RJ45 10GbE with Marvell® AQC113C
-
View AOC Options
|
|
Input / Output
|
|
USB
|
-
4 USB 2.0 ports(rear)
-
2 USB 2.0 ports(header)
-
2 ports(front)
-
2 ports(rear)
|
|
Video
|
-
1 HDMI 2.0b port
-
1 DisplayPort 1.4 port
|
|
Audio
|
|
|
TPM
|
|
|
System BIOS
|
|
BIOS Type
|
|
|
Management
|
|
Software
|
|
|
Power configurations
|
-
ACPI 6.0 Power Management
|
|
Security
|
|
Hardware
|
-
Trusted Platform Module (TPM) 2.0
|
|
PC Health Monitoring
|
|
Other Features
|
-
8-pin 12v DC power connector, ACPI power management, ATX Power connector, Chassis intrusion header, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor protection, RoHS, Voltage and Frequency Overclocking, WOL
|
|
Voltage
|
-
+1.0V PCH, +1.8V PCH, +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 3.3V standby, 5 (4-pin), CPU, CPU temperature, CPU thermal trip support, PCH temperature, System temperature, VBAT, VRM temperature
|
|
Certifications
|
|
Operating Systems
|
|
|
|
|
Chassis
|
|
Form Factor
|
|
|
Model
|
|
|
Dimensions and Weight
|
|
Height
|
|
|
Width
|
|
|
Depth
|
|
|
Package
|
-
24.9" (H) x 14.2" (W) x 24" (D)
|
|
Weight
|
-
Gross Weight: 26 lbs (11.8 kg)
-
Net Weight: 20 lbs (9 kg)
|
|
Available Color
|
|
|
Front Panel
|
|
Buttons
|
-
Power On/Off button
-
System Reset button
|
|
LED
|
-
HDD activity LED
-
Power status LED
|
|
Expansion Slots
|
|
PCI-Express (PCIe) Configuration
|
-
Default
-
2 PCIe 4.0 x8 FHFL slots
-
2 PCIe 3.0 x1 FHFL slots
-
Option A
-
1 PCIe 4.0 x16 FHFL slot
-
2 PCIe 3.0 x1 FHFL slots
-
View AOC Options
|
|
Drive Bays / Storage
|
|
Drive Bays Configuration
|
-
Default: Total 6 bays
-
6 internal fixed 3.5" SATA drive bays
-
View Drive Options
|
|
M.2
|
-
2 M.2 PCIe 3.0 x4 NVMe slots (M-key 2280/22110)
-
1 M.2 PCIe 4.0 x4 NVMe slot (M-key 2280/22110)
-
View M.2 Options
|
|
Peripheral Bays
|
|
|
System Cooling
|
|
Fans
|
-
Up to 3x 12cm heavy duty fans with optimal fan speed control
|
|
Power Supply
|
|
|
1x 750W Gold Level power supply
|
|
Dimension (WxHxL)
|
150 x 86 x 140 mm
|
|
Input
|
100-240Vac
750W: 100-240Vac / 50-60Hz
|
|
+12V
|
Max: 62A (100Vac-240Vac)
Max: 62A (100Vdc-240Vdc)
|
|
5V SB
|
Max: 3A
|
|
Output Type
|
24pin ATX
|
|
Operating Environment
|
|
Environmental Spec.
|
-
Operating Temperature: 10°C to 35°C (50°F to 95°F)
-
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
-
Operating Relative Humidity: 8% to 90% (non-condensing)
-
Non-operating Relative Humidity: 5% to 95% (non-condensing)
|
|
For detailed specifications, options, and compatibility, please refer to the latest official Supermicro documentation and the actual quotes/specifications from Autech.
產品說明
SYS-530AD-I 是 Supermicro SuperWorkstation 單處理器伺服器等級工作站。適用於遊戲與內容創作的單路中塔式工作站。
本機型面向需要可靠運算、儲存、擴充與專業圖形配置的工作站部署。主要配置參考包含 11th Gen Intel® Core™ Processors、Mid-Tower、6 default 與 1x 750W。
原廠參考連結:Supermicro 原廠產品頁面
產品特點
-
CPU:1
-
CPU 類型:11th Gen Intel® Core™ Processors
-
硬碟槽:6 default
-
外型規格:Mid-Tower
-
支援 GPU:N/A
-
電源:1x 750W
應用場景
-
專業工作站運算
-
內容創作、工程或 AI 工作負載,依實際配置而定
-
企業級工作站部署
-
專業工作站運算
-
內容創作
-
工程/模擬
-
企業級工作站部署
