• AVQ400 Series1/4磚電信模塊

AVQ400 Series1/4磚電信模塊

The AVQ400 series quarter-brick isolated DC-DC converter is designed specifically to provide a regulated low noise 12 Vdc output for feeding downstream non-isolated point-of-load (POL) converters in systems with distributed power architectures (DPA). The converter has a wide 2:1 input range of 36 to 75 Vdc and is designed primarily for use with standard 48 V telecommunications equipment supplies. Rated at 396 watts, it can deliver up to 33 amps and accommodates a wide ambient operating temperature range of -40 to 85˚C.
型號 : avq400 series

The converter has an ultra high typical efficiency of 95% and is based on an open-frame design that is optimized for forced air or conduction cooling – an aluminum baseplate option is available for enhanced thermal performance. The conversion technology employs 140 kHz fixed frequency switching to help minimize external EMI filtering requirements.

Standard features include remote enable and non-latching overvoltage and overtemperature protection. AVQ400 series converters have an installed height of just 0.37 inch (9.5 mm), making them ideal for systems with demanding inter-board spacing requirements.
  • Total Max Power:
    400 W
  • Total Max Current:
    33 A
  • Input Voltage:
    36 V to 75 V
  • Output Voltage:
    12 V to 12 V
  • Outputs:
    Single
  • Size (L x W x H):
    2.280" x 1.450" x 0.500"
  • Warranty:
    2 years
  • Operating Temperature:
    -40°C to +85°C
  • Fully regulated bus converter
  • Up to 33A output current
  • Ultra-high efficiency 93% type at full load
  • Wide input range: 36V ~ 75V
  • Excellent thermal performance
  • No minimum load requirement
  • Basic insulation
  • High power density
  • Low output noise
  • Improved thermal performance
  • RoHS 6 compliant
