• QorIQ® P20x0 VME 工業用單板電腦

QorIQ® P20x0 VME 工業用單板電腦

• NXP QorIQ P2010 and P2020 processors (800 MHz, 1.0 GHz or 1.2 GHz)
• 1GB or 2GB DDR3-800, soldered down
• Three on-board Gigabit Ethernet interfaces (one front, one rear, one configurable by customer to front or rear)
型號 : MVME250x Series

The SMART Embedded Computing MVME250x single-board computer (SBC) features the NXP® QorIQ® P2010 or dual-core P2020. The e500 v2 core QorIQ processor uses 45 nanometer technology, which delivers an industry-leading performance-to-power ratio with single-core or dual-core frequencies up to 1.2 GHz at less than 8W. This is a perfect migration path for our PowerQUICC processor boards (MVME3100 and MVME4100), as well as our G4 processor boards (MVME5100 and MVME5110). On-board memory includes up to 2GB DDR3 memory and 512KB non-volatile magneto resistive random access memory. MRAM is high speed non-volatile RAM with unlimited read/write access that protects data in the event of a power loss and does not require periodic refresh. MRAM is ideal for critical non-volatile data storage, data logs, dynamic program updates, and dynamic security. In addition the MVME2502 variant has 8GB soldered eMMC solid state memory for additional rugged, non-volatile storage. Connectivity includes Gigabit Ethernet, USB 2.0, serial ports, SATA port and either one or two PMC/XMC site with the MVME2500 and MVME2502 respectively. A hard drive mounting kit is available for Serial ATA or solid state hard drives. The extended temperature models feature an operating temperature range of -40°C to +71°C - a significant increase over the standard models' 0°C to +55°C range. Acceptable storage temperatures have also been increased, safely accommodating environments from -50°C to +100°C. The rugged variants are capable of operating under up to 5G of vibration (15 to 2000 Hz) and can withstand an 11 millisecond shock of up to 30G. Conformal coating is also available. The MVME250x series is ideal for automation, medical, and military applications such as railway control, semiconductor processing, test and measurement, image processing, and radar/sonar.



  • 800 MHz, 1.0 GHz or 1.2 GHz NXP QorIQ P2010 and P2020 processors
  • 1GB or 2GB DDR3-800, soldered down
  • Three on-board Gigabit Ethernet interfaces (one front, one rear, one configurable by customer to front or rear)
  • Five serial ports
  • One USB 2.0 port
  • One or two PCM/XMC site
  • Optional rear transition module
  • Hard drive mounting kit available
  • Optional conformal coating
  • Extended temperature (-40°C to +71°C) and rugged variants
