• XMC Expansion VME Board

XMC Expansion VME Board

• Single-slot 6U VMEbus format
• PLX PEX8533 PCI Express 6-port switch
• Support for two single-wide, or one double-wide XMC or PMC per XMCspan
型號 : XMCspan

The XMCspan board from SMART Embedded Computing allows users to customize and expand I/O options when coupled with SMART EC's MVME7100 and MVME4100 single-board computers (SBCs). When two XMCspan boards are coupled with an SMART EC MVME7100 or MVME4100, the XMCspan boards add up to four single-wide XMC slots, or four single-wide PCI Mezzanine Cards (PMCs) slots, or two double-wide XMC slots, or two double-wide PMC slots, or a combination of both XMC modules and PMC modules. (Note: This is in addition to the two single-wide PMC slots or one double-wide PMC slot on the SBC board.). This feature allows for flexibility in design and a path for future scalability. The XMCspan is a standard 6U single-slot VMEbus module that connects to its VMEbus SBC board via a PCI Express expansion connector. It supports front panel I/O access for customer supplied XMCs and/or PMCs. Additionally, the XMCspan supports a single 4-lane interface with the P15 connector for XMCs.



  • Single-slot 6U VMEbus format
  • PLX PEX8533 PCI Express 6-port switch
  • Tundra Tsi384 PCI Express to PCI-X interface bridges
  • Support for two single-wide, or one double-wide XMC or PMC per XMCspan
  • Stacking capability
  • Front-panel I/O
  • Single 4-lane interface with P15 connector for XMCs
  • Injector/ejector handles per VME64 extensions
  • Compatible with SMART EC's MVME7100 and MVME4100 VMEbus SBCs
